BALL VALVE
| Model No. | “P” Thread |
“L” + 2.0 |
Ø”D” + 2.0 |
“C” + 1.0 |
Test Pressure Hydro | |
|---|---|---|---|---|---|---|
| Body | Seat | |||||
| ARC-210-BV4 | 1/4″ NPT(F) | 58.0 | 32.0 | 14.0 | 3000 PSI | 2000 PSI |
| ARC-210-BV6 | 3/8″ NPT(F) | 58.0 | 32.0 | 14.0 | 3000 PSI | 2000 PSI |
| ARC-210-BV8 | 1/2″ NPT(F) | 75.0 | 38.0 | 19.0 | 3000 PSI | 2000 PSI |
| ARC-210-BV12 | 3/4″ NPT(F) | 80.0 | 45.0 | 19.0 | 3000 PSI | 2000 PSI |
| ARC-210-BV16 | 1.0″ NPT(F) | 87.0 | 55.0 | 22.0 | 3000 PSI | 2000 PSI |
Above item is manufactured in all the following gradess (S.S, ALLOY, C.S ,DUPLEX , SUPER DUPLEX , HASTELLOY, MONEL, INCONEL)
Note:- All dimensions are in millimeters unless otherwise specified . Dimensions are for reference only , subject to change
